NEW 2 Post Overhead 9000 Lbs Automatic Release Mechanic Lift hoist + Handlejack


$2,375.00
Item specifics

Condition

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details.



Type: 2-Post Lift Capacity: 9000lbs.

Manufacturer Part Number: Does Not Apply Brand: 5 Star

Features: Heavy Duty UPC: Does not apply




Specification and Features

Heavy Duty Design:
Column Steel Thickness: 13/64"
Carriage Steel Thickness: 15/64"
Arm Steel Thickness: 15/64"
Carriage Yoke Thickness: 5/16"
Base Plate Steel Thickness: 5/8"
Driving Mode: Dual hydraulic cylinders, chain drive
Voltage: 220V 60Hz
Lifting Capacity: 9000 LB
Combo (Symmetrical and Asymmetrical) Arm Assembly:
Straight Front/Rear 3 Stage reach from 22 7/8" to 42 5/8"
Straight Rear 2 Stage reach from 33 5/8" to 52 7/8"
Screw-in lifting pads and truck adapters included
Safety Mechanism:
Double point safety lock release
Automatic arm lock restraints
Relief valve built in power pump to prevent overloading
Door guards protection rubber
Up-limit switch to protect cylinders working stroke used in safe length scope
Heavy duty 3/8" diameter cable and 5" pulley that reduce high stress on synchronization process and increase cable life
Ultra high molecular self lubricating nylon slider that ensures carriage smooth moving up and down
Control System:
Lifting operation by pressing "UP" button on motor
Manual lowering operation by pressing lever
Relief valve built in power pump to prevent overloading
A 4 piece truck adapter set included
Overall Height: 143 3/16"
Overall Width: 134 5/16"
Minimum Height of Arm Top: 4"
Maximum Lift height with Truck Adaptor: 81"
Maximum Lift height without Truck Adaptor: 75"

Carriage to Carriage Width (Drive-through clearance): 100"
Column to Column Width: 109"
Column Cross Section: 11" L x 7" W
Time to full rise: 50 sec
Motor: 3 HP
Concrete Requirement: 6" thick at 3500 psi reinforced with steel or fiberglass
Anchor bolts/mounting hardware included
Tool trays and toe guards included
Shipping Weight: 1,590 LB
Installation Manual


NEW 2 Post Overhead 9000 Lbs Automatic Release Mechanic Lift hoist + Handlejack

FREE 3 TON COMMERCIAL AIR GO HANDLE JACK

FREE SHIPPING
